Metallyte™ QFM - Oriented Polypropylene Film

FLEXIBLE PACKAGING PRODUCT DATA SHEET

Product Description

Metallyte QFM is a high gloss, voided metallized white BOPP film with medium barrier properties. Specially designed for high speed horizontal packaging applications where medium barrier properties are required. Tailored to produce a higher yield film than standard, to provide an improved balance of yield and physical properties.

Key Features

  • Metallised exterior and high quality clean white interior
  • Designed for high speed heatseal applications (SIT 85°C)
  • Excellent hot tack
  • Good barrier properties
  • Balanced yield vs. physical properties
  • Good crease resistance for shelf appeal
  • Suitable for coldseal applications


Properties & Typical Values

PropertiesUnitQFM35Test Method
Yieldm²/kg42.6ITM 01
Unit Weightg/m²23.5ITM 01
Film Thicknessµm33ITM 02
Optical Density3.0ITM 11
Elongation at Break - MD|TD%160|45ITM 50
Minimum Sealing Temperature
(Min 300g/25mm) - 25N/cm2 - 0,5 sec - Flat/Flat
Unmetallized side
°C70ITM 26
Heat Seal Range (RDM)°C80ITM 26
Water Vapor Transmission Rate - 38°C, 90% RHg/m²/24 hr0.20ITM 46
Oxygen Transmission Rate - 23°C, 0% RHcm³/m²/24 hr30ITM 42
Breaking Load - MD|TDN/15 mm35|75ITM 50
Typical values should not be construed as finished product specifications (FPS).

Market Segments

  • Biscuits/Cookie/Crackers
  • Bakery
  • Confectionery, Chocolate
  • Health and Beauty Care
  • Ice Cream

Applications

  • HFFS Flexible Packaging

Food Contact

Any further regulatory information on this product (i.e. Food Contact application, Presence/absence of substances, Reach, …) are accessible on the below link: http://www.jindalfilms.com/login-register-docmg/

Legal Statement

This product is not intended for or supported for use in pharmaceutical or medical applications requiring compliance with EU or US Pharmacopeia.

Processing Statement

Storage

Footnotes

Revision date : May 02, 2024
