OPPalyte™ SHH - Oriented Polypropylene Film

FLEXIBLE PACKAGING PRODUCT DATA SHEET

Product Description

Oppalyte™ SHH is White voided, two side treated, BOPP film with exceptional surface gloss. For cold seal applications and use in laminates.

Key Features

  • Tailored for coldseal coating applications
  • High gloss face contributes to superb print presentation
  • Low water vapour permeability
  • Film with good bending stiffness


Properties & Typical Values

PropertiesUnitSHH 28.0SHH 40.0Test Method
Yieldm²/kg46.533.3ITM 01
Unit Weightg/m²21.530ITM 01
Film Thicknessµm27.039ITM 02
Gloss (20°)Gloss Units70ITM 14
Opacity
45:0
%7989ITM 13
Whiteness Index
45:0
7983ITM 12
Elongation at Break - MD|TD%140|45140|45ITM 50
Treatment - Treated Surfacedyne/cm>=36>=36ITM 16
Water Vapor Transmission Rate
38°C, 90% RHg/m²/24 hr5.54.0ITM 46
23°C, 85% RHg/m²/24 hr1.10.8ITM 46
Breaking Load - MD|TDN/15 mm50|7070|120ITM 50
Gloss (45°) - Treated Surface
(20°)
70ITM 14
Typical values should not be construed as finished product specifications (FPS).

Market Segments

  • Biscuits/Cookie/Crackers
  • Bakery
  • Confectionery, Chocolate
  • Ice Cream
  • Cereal Bars

Applications

  • HFFS Flexible Packaging

Processing Method

  • Cold Seal Adhesive

Food Contact

Any further regulatory information on this product (i.e. Food Contact application, Presence/absence of substances, Reach, …) are accessible on the below link: http://www.jindalfilms.com/login-register-docmg/

Legal Statement

This product is not intended for or supported for use in pharmaceutical or medical applications requiring compliance with EU or US Pharmacopeia.

Processing Statement

Storage

Footnotes

Revision date : March 15, 2024
