OPPalyte™ SVD - Oriented Polypropylene Film

FLEXIBLE PACKAGING PRODUCT DATA SHEET

Product Description

OPPalyte™ SVD is a high gloss white voided BOPP film with a low threshold sealing layer (100°C) designed for VFFS applications, suitable for laminates. The film has a modified intermediate layer that promotes easy opening (peelable).

Key Features

  • Easy opening, enhanced heat sealing threshold layer (100°C) for VFFS packaging machines
  • Tailored and consistent slip
  • High gloss face contributes to superb print presentation
  • Good moisture barrier
  • Easy opening feature
  • Not suitable for boost treatment


Properties & Typical Values

PropertiesUnitSVD 28.0Test Method
Yieldm²/kg47.6ITM 01
Unit Weightg/m²21ITM 01
Film Thicknessµm28ITM 02
Gloss (20°)Gloss Units50ITM 14
Opacity
45:0
%83ITM 13
Whiteness Index
45:0
83ITM 12
Elongation at Break - MD|TD%140|45ITM 50
Heat Seal Range (RDM) - Untreated Surface°C100-140ITM 26
Coefficient of Friction0.3ITM 20
Treatment - Treated Surfacedyne/cm>=36ITM 16
Water Vapor Transmission Rate - 38°C, 90% RHg/m²/24 hr4.8ITM 46
Breaking Load - MD|TDN/15 mm40|65ITM 50
Heatseal strength
Untreated Surface
N/15 mm1.5ITM 26
Typical values should not be construed as finished product specifications (FPS).

Market Segments

  • Biscuits/Cookie/Crackers
  • Bakery
  • Confectionery, Chocolate
  • Crisps and Snacks

Applications

  • HFFS Flexible Packaging
  • VFFS Flexible Packaging

Food Contact

Any further regulatory information on this product (i.e. Food Contact application, Presence/absence of substances, Reach, …) are accessible on the below link: http://www.jindalfilms.com/login-register-docmg/

Legal Statement

This product is not intended for or supported for use in pharmaceutical or medical applications requiring compliance with EU or US Pharmacopeia.

Processing Statement

Storage

Footnotes

Revision date : May 14, 2024
